BNL LHC D2 and D4 Magnet Coil and Collar Insulation Details
Coil insulation includes 5 mil Kapton caps and b-staged adhesive on the pole and midplane. Quench resistor insulation comprises 1 mil Kapton and adhesive. Collar insulation consists of 2 x 5 mil Kapton caps. Cable insulation layers and materials between coil and heater, and heater and collar, are detailed in the summary provided.
Download Presentation
Please find below an Image/Link to download the presentation.
The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author.If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.
You are allowed to download the files provided on this website for personal or commercial use, subject to the condition that they are used lawfully. All files are the property of their respective owners.
The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author.
E N D
Presentation Transcript
BNL LHC D2 and D4 magnet coil and collar insulation M. Anerella, J. Schmalzle April 2, 2019
Coil insulation: 5 mil Kapton caps (and b- staged adhesive) on pole and midplane
Summary Between coil and heater: 2 x 1 mil Cable insulation minimum (2 wrap layers, 48% overlap each) 2 mil Teflon + 1.5 mil adhesive (thermal only no insulating value) 5 mil Kapton cap (with seam) + 1.5 mil b-staged adhesive 1 mil heater Kapton + 1.5 mil adhesive 2 layers of Kapton minimum everywhere Between heater and collar: 1 mil heater Kapton + 1.5 mil adhesive 5 mil Kapton + 1.5 mil b-staged adhesive 5 mil Kapton+ 1.5 mil b-staged adhesive 2 layers of Kapton minimum everywhere (3 layers in body, ends staggered for 2 layers)
