1. MSQC1, MS Qual/Quant QC Mix

2. MS Qual/Quant QC Mix (Sigma- Aldrich) is intended for daily use to assess platform characteristics, including: Repeatability System stability (drift, chromatography, signal intensity, sensitivity, etc.) Inter- and intra-platform and lab comparisons

3. XIC for 3 peptides with their havey versions (MSQC1 standard QC from sigma)

4. XIC for 3 peptides with their havey versions (MSQC1 standard QC from sigma)

5. XIC for 5 peptides with their havey versions (MSQC1 standard QC from sigma)

6. Table 2. shows the difference between RatioToStandard Vs Theoretical ratios. (Results Report, from Skyline) Peptide Sequence PeptidePeakFoundRatio RatioToStandard (L/H) Theoretical ratio 2 VLDALQAIK 1 2.0789 1 GGPFSDSYR 1 0.9873 50 SADFTNFDPR 0.67 34.6957 10 AVQQPDGLAVLGIFLK 0.67 5.2727 1 ALIVLAHSER 0.67 0.7895 2 EGHLSPDIVAEQK 1 1.2599 50 GYSIFSYATK 1 29.5 10 ESDTSYVSLK 0.83 7.3286 0.5 FEDENFILK 1 0.2171 1 VSFELFADK 0.83 0.4646 50 NLSVEDAAR 0.67 13.6667 10 FSTVAGESGSADTVR 0.5 2.5

7. Correlations curve between theoretical Vs Ratio toStandard Run, with R=0.8179 70 60 R = 0.8179 50 40 30 20 10 0 0 10 20 30 40 50 60 70 Theoretical Ratio

8. Table 2. shows the difference between RatioToStandard Vs Theoretical ratios. (Results Report, from Skyline) Peptide Sequence PeptidePeakFoundRatio RatioToStandard (L/H) Theoretical ratio 2 VLDALQAIK 1 2.0789 1 GGPFSDSYR 1 0.9873 50 SADFTNFDPR 0.67 34.6957 10 AVQQPDGLAVLGIFLK 0.67 5.2727 1 ALIVLAHSER 0.67 0.7895 2 EGHLSPDIVAEQK 1 1.2599 50 GYSIFSYATK 1 29.5 10 ESDTSYVSLK 0.83 7.3286 0.5 FEDENFILK 1 0.2171 1 VSFELFADK 0.83 0.4646 10 FSTVAGESGSADTVR 0.5 2.5

9. Correlations curve between theoretical Vs Ratio toStandard Run, with R=0.9796 60 R = 0.9796 50 Ratio toStandard Run 40 30 20 10 0 0 5 10 15 20 25 30 35 40 Theoretical Ratio

10. Sensitivity comparison between 4000 Vs 5500 Qtrap for NLSVEDAAR peptide. Peak area is 5 times higher in 5500 QTRAP 5500 4000

11. Sensitivity comparison between 4000 Vs 5500 Qtrap for NLSVEDAAR peptide. Peak area is 5 times higher in 5500 QTRAP 5500 4000
