1. Haystack Labs Introducing Systems Mike Melillo Albireo Energy

2. Purpose Formalize a logical grouping mechanism to Haystack Standardize what most practitioners already do with an equipType tag or similar. 2

3. Key Features Extensible for future working groups and expansion to Haystack Alignment with existing work by Brick Navigation styles (site/space/equip vs site/system/equip) Co-Membership with systemRef: [@123,@abc] 3

4. Formal Def 4

5. Example CHW/CW System {id:@chwSys, chilled, water, system} ____ {id:@cwSys, condenser, water, system} ____ {id:@ch, equip, chiller, systemRef: [@chwSys, @cwSys]} ____ {id:@hx, equip, heatExchanger, systemRef: [@chwSys, @cwSys]} ____ {id:@chwp, equip, chilled, water, pump-motor, systemRef: @chwSys} ____ {id:@cwp, equip, condenser, water, pump-motor, systemRef: @cwSys} ____ {id:@ct, equip, coolingTower, fan-motor, systemRef: @cwSys} 5

6. Example CHW/CW System {id:@chwSys, chilled, water, system} ____ {id:@cwSys, condenser, water, system} ____ {id:@ch, equip, chiller, systemRef: [@chwSys, @cwSys]} ____ {id:@hx, equip, heatExchanger, systemRef: [@chwSys, @cwSys]} ____ {id:@chwp, equip, chilled, water, pump-motor, systemRef: @chwSys} ____ {id:@cwp, equip, condenser, water, pump-motor, systemRef: @cwSys} ____ {id:@ct, equip, coolingTower, fan-motor, systemRef: @cwSys} 6

7. Example CHW/CW System {id:@chwSys, chilled, water, system} ____ {id:@cwSys, condenser, water, system} ____ {id:@ahu, equip, chilledWaterCooling, systemRef: @chwSys} ____ (OR!) {id:@ahu, equip} {id:@clgCoil, equipRef: @ahu, equip, coolingCoil, chilledWaterCooling, systemRef: @chwSys} Allow flexibility to create as detailed a model as required, Allow flexibility to create as detailed a model as required, while still being able to take advantage of the new system while still being able to take advantage of the new system def. def. 7

8. Links/Resources https://project-haystack.org/doc/lib-phIoT/system https://project-haystack.org/doc/docHaystack/Systems https://github.com/Project-Haystack 8

9. DEMO 9
