GRAINSIZE GRAINSIZE 1
Grainsize Charm++ philosophy: Let the programmer decompose their work and data into coarse- grained entities It is important to understand what I mean by coarse-grained entities You don t write sequential programs that some system will auto- decompose You don t write programs when there is one object for each float You consciously choose a grainsize, but the number of processors Or parameterize it, so you can tune later but choose it independently of 2 Charm Tutorial
Crack Propagation This is 2D, circa 2002... but shows overdecomposition for unstructured meshes Decomposition into 16 chunks (left) and 128 chunks, 8 for each PE (right). The middle area contains cohesive elements. Both decompositions obtained using Metis. Pictures: S. Breitenfeld, and P. Geubelle Charm Tutorial 3
Working definition of grainsize: amount of computation per remote interaction Choose grainsize to be just large enough to amortize the overhead 4 Charm Tutorial
Rules of Thumb for Grainsize Make it as small as possible, as long as it amortizes the overhead More specifically, ensure: Average grainsize is greater than k v (for some k, say 10v) v: overhead per message No single grain should be allowed to be too large Must be smaller than T/p, where p: number of processors, T: sequential execution time Can generalize by saying must be smaller than k m v (say 100v) Important corollary: You can be at close to optimal grainsize without having to think about p, the number of processors 5 Charm Tutorial
Grainsize in a common setting 2 MB/chare, 256 objects per core number of points per chare 6
Grainsize: Weather Forecasting in BRAMS BRAMS: Brazillian weather code (based on RAMS) AMPI version (Eduardo Rodrigues, with Mendes, J. Panetta, ..) Instead of using 64 work units on 64 cores, used 1024 on 64 7 Charm Tutorial
Baseline: 64 Objects Profile of Usage for Processors 0- -63 Time per Step: 46s Profile of Usage for Processors 0 Time per Step: 46s 63 100 90 80 70 Usage Percent (%) Usage Percent (%) 60 50 40 30 20 10 0 0 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 PE 34 36 38 40 42 44 46 48 50 52 54 56 58 60 62 Avg PE 8 Charm Tutorial
Overdecomposition: 1024 Objects Profile of Usage for Processors 0 Time per Step: 33s Profile of Usage for Processors 0- -63 Time per Step: 33s 63 100 90 80 70 Usage Percent (%) Usage Percent (%) 60 50 40 30 Benefits from 20 communication/computation overlap 10 0 0 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 PE 34 36 38 40 42 44 46 48 50 52 54 56 58 60 62 Avg PE 9 Charm Tutorial
With Load Balancing: 1024 objects Usage Profile for Processors 0 Time per Step: 27s Usage Profile for Processors 0- -63 Time per Step: 27s 63 100 90 80 70 Usage Percent (%) Usage Percent (%) 60 50 No overdecomp (64 threads) + Overdecomposition (1024 threads) + Load balancing (1024 threads) 46 sec 33 sec 27 sec 40 30 20 10 0 0 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 PE 34 36 38 40 42 44 46 48 50 52 54 56 58 60 62 Avg PE 10 Charm Tutorial
