GRIHA Exemplary Performance Awards

GRIHA Exemplary Performance Awards Guidelines for GRIHA projects# 1. For participation in the aforementioned award category, the project team should fill the presentation template that is given with the guidelines, in .pptx format. 2. Project team must explain their strategies as per the instructions given under in the subsequent slides and support it with pictures. The presentation should not exceed a maximum of 15 slides. Additionally, separate presentations need to be submitted for each category. 3. The project team may mention their ongoing or completed interventions. Proposed plans may not be included in the presentation. 4. Winners will be announced during the GRIHA Event on 10 December, 2021. 5. It is compulsory to include case study card details which is a summary of your presentation on the last slide 6. The project team must submit group photographs in one of the slides. 7. Please submit your entries griha.awards@gmail.com on or before 8 October, 2021. 8. For any further queries, please get in touch with Ms Ichhita Handa at griha.awards@gmail.com 9. A one line quote also needs to be submitted. This could be a short message that the team would like to convey to the viewers. #Only registered/on-going GRIHA projects are eligible for EP awards.

GRIHA Exemplary Performance Awards Category - High resolution image of the project (for website & social media) (Please provide Image in JPG format) Please submit the presentation in .PPTX format. Project Name: Project Location:

GRIHA Exemplary Performance Awards Project brief Project name GRIHA project code Location Site area m Built up area m No. of storey No. of building blocks Typology .(Residential, commercial, institutional etc.) Type of Building (air conditioned / non-air conditioned)

GRIHA Exemplary Performance Awards Project explanation (Separate presentation for each category) 1. Energy management The project team needs to demonstrate optimization of energy consumption through efficient lighting/ HVAC/ system designing If the project team has an efficient operation and maintenance protocol which can optimize energy consumption of the project 2.Passive architecture design The project team needs to demonstrate the strategies in which natural site features (topographical/microclimatic) can be protected and incorporated into the project design. 3. Sustainable building materials /technologies The project team needs to demonstrate the use of locally available materials and material with high recycle content(like fly-ash or any other BIS recommended waste) If the project is using any innovative technologies to reduce embodied energy in building structure (like pre-cast, PT slabs, coffered slab etc.) NOTE: Please submit separate presentations for different categories.

GRIHA Exemplary Performance Awards Project explanation (not more than 10 slides) Refer as per the category 4. Integrated water management The project team needs to demonstrate the water saving, recycling and reuse on site (towards net zero/ net positive approach) If the project is implementing any innovative storm water management scheme 5. Renewable energy utilization The project team needs to demonstrate the renewable energy generation on site (towards net zero/ net positive energy approach) 6. Site management (During construction) The project team needs to demonstrate the best site management practices during construction. 7. Construction workers health and safety (During construction) The project team needs to demonstrate the safe, healthy and hygienic working & living conditions for construction workers working in the project. NOTE: Please submit separate presentations for different categories.

GRIHA Exemplary Awards GRIHA Exemplary Performance Awards Summary (not more than 1-2 slides) 1. Energy management List the strategies opted in the project to reduce the energy consumption o SHGC of project o WWR of project o Brief about HVAC system installed o Specifications of HVAC system installed o Others Type of external lighting fixtures installed Efficiency of motors installed Operation and maintenance o O&M policy o Training for maintenance o Contract for O&M o List of maintenance team List of energy meters such as HVAC, RE, external lighting, common area, etc. installed in the project. Reduction of energy consumption (%) (HVAC and internal lighting) o Benchmark EPI: .KWh/ m2/year o Proposed EPI: KWh/ m2/year

GRIHA Exemplary Awards GRIHA Exemplary Performance Awards Summary (not more than 1-2 slides) Refer as per the category 2. Passive architecture design List the strategies opted in the project Impact analysis 3. Sustainable building materials /technologies List the materials/technologies used in the project Structural application Materials used in wall Materials used in roof Interior finishes Exterior finishes Reduction in embodied energy in structural application (%) Reduction in embodied energy in non-structural application (%) Percentage of low energy material used in the project.

GRIHA Exemplary Awards GRIHA Exemplary Performance Awards Summary (not more than 1-2 slides) Refer as per the category 4. Integrated water management Briefly describe the water management strategies to reduce building and landscape water consumption. Reduction in landscape water consumption (%) Reduction in building water consumption (%) List of native and exotic species planted on site. Irrigation system installed in the project. Water used for various purposes meets the Bureau of Indian Standards (BIS) Recycling and reusing treated waste water in the project. Provision of rainwater harvesting pits and rainwater storage in the project. 5. Renewable energy utilization (solar PV, solar hot water, wind, biomass etc.) Overall energy consumption of internal artificial lighting and space conditioning Percentage of renewable energy system to offset the energy consumption for internal artificial lighting and space conditioning Rated capacity of renewable energy system installed on site/off site Type of Renewable Energy system installed

GRIHA Exemplary Awards GRIHA Exemplary Performance Awards Summary (not more than 1-2 slides) Refer as per the category 6. Site management (During construction) List of key features of best site management practices opted during construction. 7. Construction workers health and safety (During construction) List of key features of the initiatives taken for construction workers working in the project.

GRIHA Exemplary Performance Awards Contact details Contact person Name Designation Organization Mobile no. Email id Nominees for the Award Evening (Maximum 2 people) S. No. 1 2 Name Email Phone no.

GRIHA Exemplary Performance Awards Case Study Card details Project Name: Project Location: Exemplary Award (category): Key Features Energy Management: Energy Consumption Reduction (%) Glass specifications Comfort Systems and controls Natural ventilation design requirements Space conditioning equipment efficiencies (AHUs, cooling towers, chillers, pumps etc.) Piping and ductwork insulation Lighting control details Electrical systems efficiencies (Transformers, DG sets, HT & LT panels, motors, power factor etc.)

GRIHA Exemplary Performance Awards Case Study Card details Project Name: Project Location: Exemplary Award (category): Key Features Passive Architecture Design: Green Infrastructure (tree preservation, land-use optimization, reduce transport emissions) Low impact design strategies (solar design strategies, wind design strategies, daylighting strategies) Contribution to urban heat phenomenon (shading, green cover, high SRI surface finishes) Contextual design with respect to its surrounding built environment Early stage design optimization for resource efficiency Preservation and enhancement of natural biodiversity

GRIHA Exemplary Performance Awards Case Study Card details Project Name: Project Location: Exemplary Award (category): Key Features Sustainable Building Materials / Technologies: Material specifications (recycled content, locally available, low-embodied energy, etc.) Construction or demolition waste used in construction of roads, vehicular pathways, pavements / footpaths, etc. Wall / Roofing materials specifications External / internal finishes specifications

GRIHA Exemplary Performance Awards Case Study Card details Project Name: Project Location: Exemplary Award (category): Key Features Integrated Water Management: Types of low-flow fixtures installed Waste water management systems (STP, WTP, ETP, rain water harvesting pits, irrigation systems etc.)

GRIHA Exemplary Performance Awards Case Study Card details Project Name: Project Location: Exemplary Award (category): Key Features Renewable Energy Utilization: Type of RE system installed (solar PV, solar hot water, windmills, bio-gasifiers, geothermal etc.)

GRIHA Exemplary Performance Awards Case Study Card details Project Name: Project Location: Exemplary Award (category): Key Features Site Management During Construction: Strategies adopted to minimize contamination and wastage of water Strategies adopted for safe disposal of waste generated Strategies adopted to prevent loss of vegetation & fertile soil Strategies adopted to reduce harmful emissions & dust generation Strategies adopted to minimize & monitor consumption of water

GRIHA Exemplary Performance Awards Case Study Card details Project Name: Project Location: Exemplary Award (category): Key Features Construction workers health & safety: Provision of necessary safety equipment & safety measures Provision of hygienic working & living conditions Provision of clean drinking water & sanitation facilities Provision of cr che facility for children of construction workers Provision of grocery store / canteen within the site premises
