Summer Solar Panel Shade Analysis Chris Jones Santa Rosa, CA 7/15-7/27/2023 Topic Page House SW Roof 2 House SE Roof Garage SE Roof
House SW Roof Time Voltage Power kWh Observations with both trees present Projection if valley oak removed 8 AM 9 AM 10 AM 11 AM Noon 1 PM 2 PM 3 PM 4 PM 5 PM
House SE Roof Time Observations with both trees present Projection if valley oak removed 8 AM Partial shade on far surface from neighbor s house Partial shade on far surface from neighbor s house 9 AM No shade No shade 10 AM No shade No shade 11 AM No shade No shade Noon No shade No shade Telephone pole shade; remove telephone pole? 1 PM Telephone pole shade 2 PM Valley oak starting to shade No shade 3 PM Valley oak shading most of near surface over family room and part of far surface No shade 4 PM Almost complete shade from valley oak, and partial shade from magnolia; but SE panel angle sub-optimized by this point Partial shade from magnolia; but SE panel angle sub- optimized by this point 5 PM Sunset Sunset
Garage SE Roof Time Observations 8 AM No shade 9 AM No shade 10 AM No shade 11 AM No shade Noon No shade 1 PM Telephone pole shade 2 PM Telephone pole shade 3 PM No shade 4 PM No shade 5 PM Sunset
