Update from RIPTIDE lab
Outlining the latest developments at the RIPTIDE lab meeting including setting up the trigger for the ASI camera, MCP status, purchased materials, and planned purchases. Details on the ASI camera trigger setup with oscilloscope signals, Labview integration, and output options. Additionally, the MCP status and upcoming shopping plans are highlighted.
Download Presentation
Please find below an Image/Link to download the presentation.
The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author.If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.
You are allowed to download the files provided on this website for personal or commercial use, subject to the condition that they are used lawfully. All files are the property of their respective owners.
The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author.
E N D
Presentation Transcript
Update from RIPTIDE lab RIPTIDE meeting 11/09/2024 Claudia Pisanti UniBO & INFN BO Alberto Mengarelli INFN BO
Outline 1. Trigger for ASI camera 2. MCP status 3. Purchased material
Trigger for the ASI Camera: Set-up Oscilloscopio Signal from the PMT Signal after reshaping Black box ASI 533 + optics PMT blue LED Discriminator Dual Timer At 1200 Volt. Pulsed with ARDUINO - 1 ms ON - 5000 ms OFF To Arduino UNO Analog PIN facing the LED Sig IN : ~50 mV Output USB to the LAPTOP Output USB to the LAPTOP Threshold: 30 mV Sig OUT : ~1.7 V Time width from ns to ms
Trigger for the ASI Camera: Labview In Labview pre-build libraries for ARDUINO and ASI-Camera LabView acquisition software 1. 2. Start camera exposure Wait for the PMT Trigger signal from ARDUINO Stop camera exposure Save DATA 3. 4.
Trigger for the ASI Camera: Output TRIGGER.mp4 Output on the camera
MCP Status MCP is in out lab! need to make it work
Shopping June/July 2024 From Thorlabs: - Laser 405 nm, mounting rings and lenses, screw kit, cleaning set, mirror and holders ~ 1.5 keuro (M4 instead of M6) From RS: - Banana-banana cables (10 red + 10 black), coaxial cable 50 m 75 , connectors (micro bnc) ~ 300 euro (After 16 Oct.)
