1. RE-COMPLETION G L -2 WEST AK AKOCA-1 AK AKOCA-3 LOG EVALUATION & PERFORATION 26.10.2023 PARK PLACE ENERGY

2. RESERVE MAP PARK PLACE ENERGY

3. WELL LOCATION & TRAJECTORY AK AKOCA PLATFORM MD: 3839m TVDSS: -1594m MD: 2200m TVDSS: -1636.4m MD: 1725m TVDSS: -1583.4m MD: 3910m TVDSS: -1589.85m MD: 1954m TVDSS: -1476.6m MD: 1706m TVDSS: -1685m MD: 2826.7m TVDSS: -1510.9m PARK PLACE ENERGY

4. GL-2 PARK PLACE ENERGY

5. Sand C Pay Interval (m) (MD) (TVD) 3644.04 3653.85 (1366.58-1375.04) 9.81 m (8.46 m) 3646.53m (MD); 1369.30m (TVD); 1336.04m (TVDSS) Max Tot. Gas % 0.52 GAS PAY 3644.5 3644.04 m e % 21 3.0 m Vclay % 35 Sw 58 9.81 m Sw % 58 3647.5 Resistivity up to 7.1 ohm.m 3653.85 m GAS PAY 3665.0 Pay Interval (m) (MD) (TVD) 3665.22 3674.52 (1386.12-1394.77) 9.30 m (8.65 m) 3665.22 m 6.0 m Sw 55 3672.63m (MD); 1393.47m (TVD); 1360.21m (TVDSS) 9.30 m Max Tot. Gas % 0.73 3671.0 e % 21 3674.52 m Vclay % 22 Sw % 55 Resistivity up to 11.2 ohm.m *Apprx. 27 cm shift for 25.3 penetration 23 deviation Gas Pay 9.30 m Gas Pay 9.81 m in Perforation 3665.0- 3671.0 Perforation 3644.5- 3647.5 6.00 m 3.00 m PARK PLACE ENERGY

6. Sand B (Deeper) 3579.42 3585.06 (1308.52- 1313.47) Pay Interval (m) (MD) (TVD) 5.64 m (4.95 m) 3583.64m (MD); 1312.68m (TVD); 1279.42m (TVDSS) Max Tot. Gas % 1.05 GAS PAY 3580.0 3579.42 m e % 20 5.0 m 5.64 m Sw 48 Vclay % 24 Sw % 48 3585.0 3585.06 m Resistivity up to 12.7 ohm.m Gas Pay 5.64 m Perforation 3580.0- 3585.0 5.00 m *Apprx. 32 cm shift for 25.3 penetration in 28 deviation PARK PLACE ENERGY

7. Gl-2 - Sand A GAS PAY 3512.06 m 3512.0 2.0 m 2.74 m Sw 49 3514.0 3514.80 m Pay Interval (m) (MD) (TVD) 3512.06 - 3514.80 (1251.27-1253.60) 2.74 m (2.33 m) Max Tot. Gas % 3513.05m (MD); 1252.13m (TVD); 1218.87m (TVDSS) Gas Pay 2.74 m 1.06 e % 20 Perforation 3512.0- 3514.0 2.00 m Vclay % 20 Sw % 49 Resistivity up to 7 ohm.m PARK PLACE ENERGY

8. Sand AA GAS PAY 3502.15 m 3504.5 6.1 m 3.0 m Sw 55 3508.25 m 3507. 5 Pay Interval (m) (MD) (TVD) 3502.15 3508.25 (1242.62-1247.68) 6.10 m (5.07 m) Max Tot. Gas % 3504.55m (MD); 1245.01m (TVD); 1211.75m (TVDSS) Gas Pay 6.1 m 2.24 e % 19 Perforation 3504.5- 3507. 5 3.0 m Vclay % 27 Sw % 55 *Apprx. 35 cm shift for 25.3 penetration in 33 deviation Resistivity up to 7 ohm.m PARK PLACE ENERGY

9. WEST AKAKOCA-1 PARK PLACE ENERGY

10. W.AK-1 Sand B - Perforation Pay Interval (m) (MD) (TVD) 3491.8 3493.0 (1329.3-1330.2) 1.2 m (0.9 m) 3491.9 m (MD); 1329.4 m (TVD); 1296.1 m (TVDSS) Max Tot. Gas % 1.91 e % Vclay % Sw % 22 24 50 up to 4.5 ohm.m Resistivity Gas Pay 1.2 m Perforation (3492.0 - 3493.0) 3492.0 1.0 m 1.0 m Sw 50 4.5 .m 3493.0 Shale

11. W.AK-1 Sand A - Perforation 3425.2 3426.3 (1282.9- 1283.6) Pay Interval (m) (MD) (TVD) 1.1 m (0.7 m) 3425.2 m (MD); 1282.9 m (TVD); 1249.7 m (TVDSS) Max Tot. Gas % 1.74 e % Vclay % Sw % 22 14 50 3425.0 1.0 m up to 5.7 ohm.m 5.7 .m 3425.2 3426. 3 Resistivity Sw 50% 3426.0 Gas Pay 1.1 m Perforation (3425.0 - 3426.0) 1.0 m 3454.0 3453.2 5.0 m Sw 48% 7.1 .m 3459.0 3459.3 Pay Interval (m) (MD) (TVD) 3453.2 3459.3 (1301.7-1305.9) 6.1 m (4.2 m) Gas Pay 6.1 m 3457.2 m (MD); 1304.5 m (TVD); 1271.2 m (TVDSS) Max Tot. Gas % 1.00 Perforation (3454.0 - 3459.0) 5.0 m e % Vclay % Sw % Resistivity 21 18 48 *Apprx. 62 cm shift for 25.3 penetration in 45 deviation up to 5.9 ohm.m

12. W.AK-1 Sand AA - Perforation 3395.3 3398.7 (1264.0- 1266.1) Pay Interval (m) (MD) (TVD) 3.4 m (2.1 m) 3395.3 m (MD); 1264.0 m (TVD); 1230.8 m (TVDSS) Max Tot. Gas % 0.72 e % Vclay % Sw % 22 14 55 up to 7 ohm.m Resistivity Gas Pay 3.4 m Perforation (3395.0 - 3398.0) 3.0 m 3395.0 3395.3 3.0 m 3.8 .m Sw 55% 3398.0 3398.7 Tight 6 0 % PARK PLACE ENERGY

13. AKAKOCA-3 PARK PLACE ENERGY

14. Akakoca-3 (Re-Comp) GAS PAY PERFORATION INTERVALS RESERVOIR INTERVAL m (MD) INTERVAL m (MD) V clay (%) THICKNS THICKNS Sw (%) (%) m m Top Bottom Top Bottom SAND C Re- Perf 1839.0 REMANINING PERFS 1836.5 1843.5 7.0 10 25 44 1839.01843.0 (4.0) 1st RUN 4.0 m 1843.0 SAND E 2001.0 2013.3 12.3 20 19.5 58 2009.52015.5 (6.0) 2nd RUN PERF ED & PRODUCED 0.34 BCF in 138 Days SAND B 1741.0 1750.0 9.0 18 25.8 55 1741 1748 7 2009.5 Cum. Production= 0.34 bcf 6.0 m 2015.5 Remaining total Gas Pay 25.9 m E, C Sands
